GIGE Series
WP-GS5105 MP GigE Global-Shutter Industrial Camera
The most mainstream mid-range spec: 5 MP global shutter balancing detail against speed — the balanced pick for line cosmetic inspection and dimension checking.
- 5 MP
- global shutter
- GigE
- 100 m cable
- Mid-range
- workhorse
WP-GS510 · Color · Bayer outputWP-GS510M · Mono · NIR-enhanced
Request a QuoteDownload Datasheet — Datasheet in preparation — request via inquiry
Full Specifications
Source: manufacturer manual V24.05 · 2026-08
Imaging
| Resolution | 5 MP |
|---|---|
| Shutter | Global |
| Sensor | 2/3" CMOS, global shutter |
Interface & Triggering
| Data interface | GigE Vision |
|---|---|
| Bandwidth | 1000 Mbit/s |
| Max cable length | 100 m (Cat 5e/6) |
Mechanical & Environmental
| Lens mount | C-mount |
|---|---|
| Certifications | CE / FCC / RoHS |
Software
| Software support | GigE Vision / GenICam · SDK: Halcon / OpenCV / LabVIEW |
|---|---|
| OS support | Windows / Linux / ARM |
Applications
Recommended Accessories
5 MP-class FA lens
≥5 MP optics to match; focal length per field of view.
Ring / backlight
Ring light for surface inspection, backlight for dimensioning. Send a sample photo for a lighting plan.
Series Comparison
Request a Quote
Tell us your scene (field of view, cycle time, smallest defect) — we propose lens and lighting for WP-GS510, quote within 24 hours.
